Double Core 8-Shaped Optical Cable(ZCC)
Double Core 8-Shaped Optical Cable(ZCC)
Double Core 8-Shaped Optical Cable(ZCC)
Double Core 8-Shaped Optical Cable(ZCC)

Double Core 8-Shaped Optical Cable(ZCC)

A dual-core figure-8 optical cable using 900μm or 600μm tight-buffered optical fibers as optical transmission units, with aramid yarns as strength members, and finally extruded with a layer of figure-8 polyvinyl chloride (PVC) sheath. Alternatively, a low smoke zero halogen (LSZH) material sheath can be provided according to customer requirements

DETAILS


◆ The use of tight-buffered optical fibers facilitates easy stripping.

◆ Tight-buffered optical fibers exhibit excellent flame retardancy.

◆ Aramid yarn strength members provide outstanding tensile performance for the cable.

◆ The outer sheath material offers corrosion resistance, waterproofing, flame resistance, and environmental friendliness.

The 8 shaped structure facilitates easy stripping for branch usage

•Fiber optic patch cords or pigtails for active connections.

•Indoor riser and plenum cabling for vertical shafts and forced ventilation.

•Interconnection of instruments and communication equipment.

Note:

This document is for reference only and cannot be used as an attachment to the contract.

For detailed product information, please contact our sales staff.
